SAFETY AND INSTALLATION - UNIMOTOR FM & HD

MECHANICAL DIMENSIONS

Shaft diameter
(ØD)
>9-13
>13-16
>16-21
>21-24
>24-30
>30-38
>38-48
PCD Mounting
(ØA) Bolt
63 + 0.4 M5
66.7 + 0.4 M5
70 + 0.4 M5
75 + 0.4 M5
80 + 0.4 M5
85 + 0.4 M6
98.43 + 0.4 M6
100 + 0.4 M6
115 + 0.4 M8
115 + 0.4 M8
125.73 + 0.4 M8
130 + 0.4 M8
145 + 0.4 M8
149.23 + 0.4 M8
165 + 0.4 M10
215 + 0.4 M12
300 + 0.4 M16
Safety and installation - UNIMOTOR FM & HD
4100 en - 2017.08 / c
Tapped hole
(E)
M4
M5
M6
M8
M10
M12
M16
Register
(ØB)
40 (j6)
60 +0/-0.05
50 (j6)
60 (j6)
60 (j6)
70 (j6)
73.025 +0/-0.05
80 (j6)
95 (j6)
95 (j6)
110 +0/-0.05
110 (j6)
110 (j6)
114.3 +0/-0.076
130 (j6)
180 (j6)
250 (j6)
fm motor hd motor
Frame size Frame size
055
075
055
075
075
075
095
095
095
115
115
115
115
142
142
190
250
en
055
-
-
067
-
-
-
089
-
-
-
115
-
-
-
-
-
17
