2.2. Technical characteristics
•
12,5cm (5 ") color TFT display with 320 x 240 pixels
•
DVB-C channel search (cable network)
•
DVB-S & S2 channel search (satellite system)
•
DVB-T & T2 channel search (terrestrial plants)
•
Live TV display with audio
•
Spectrum analyzer for all DVB functions
•
Integrated TV recording function in the receiver format
•
Media player for playback of photos and videos
•
16QAM and QPSK to 256QAM / 8PSK demodulator
•
Fast 450MHz processor and 256 MB SDRAM
•
HDMI & AV IN / OUT, and USB ports
•
Video decoder with 576i to 1080p scaling
•
Rugged metal case and holster with carrying strap
•
Removable lithium-ion battery with 2500mAh
•
Safety: EN 60950-1
3. Technical Data
Satellite
Standard
Frequency range
LNB-Control
Level range
Accuracy
DiSEqC
Demodulation (DVB-S)
Demodulation (DVB-S2)
Symbol rate
Terrestrial
Standard
Frequency range
Level range
Accuracy
Antenna supply
Demodulation (DVB-T)
Demodulation (DVB-T2)
Cable
Standard
Frequency range
Level range
Accuracy
Demodulation (DVB-C)
Symbol rate
System
Processor
SD-RAM
Flash
DVB-S / DVB-S2
950 MHz - 2150 MHz
13/18V, max 400mA.; 22kHz
-65dBm ~ -25dBm
C/N +/- 0,1 dB; Level +/- 0,1 dBµV
Version 1.0 / 1.1
QPSK
QPSK, 8PSK
2 Mbps~ ~45 Mbps
DVB-T / T2
110 MHz – 862 MHz
-93dBm ~ -35dBm
C/N +/- 0,1 dB; Level +/- 0,5 dBµV
5V, max 50mA
QPSK,16QAM, 64QAM
QPSK,16QAM, 64QAM, 256QAM
DVB-C
110 MHz – 862 MHz
-93dBm ~ -35dBm
C/N +/- 0,1 dB; Level +/- 0,5 dBµV
16QAM, 32QAM, 64QAM, 128QAM, 256QAM
0.2 Mbps ~ 7.2 Mbps
450 MHz
256 MByte
2MByte NOR + 128 MByte NAND
-42-
