Required Tools
Supplied Parts and Hardware
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the
damaged item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: M4, M6, or M8 describes the diameter, mm describes the length of screws that are labeled M# X ##mm. Not all
hardware included will be used.
[01]
[01]
4
[02]
If mounting to a TV with a 200 x 200 mm (7 7⁄8 x 7 7⁄8 in.) hole pattern, add the
extension plates [03] to the TV bracket [01] using the extension plate screws [14]
and nuts [15].
[03]
[14]
[15]
10 mm
11 mm
(3/8 in.)
(7/16 in.)
Wall plate [02] is shipped attached to the TV bracket [01]. Remove wall
plate [02] before starting installation.
[01]
3 mm
(1/8 in.)
[02]
6902-002028 <00>
