Specifi cations
-DO NOT EXCEED:
Weight capacity
CAUTION:
Avoid potential personal injuries and property damage!

Do not use this product for any purpose not explicitly specifi ed by manufacturer.

The wall must be capable of supporting fi ve times the weight of the monitor and mount combined.

This product includes directions and hardware for use with wood stud, solid concrete and concrete block walls. For information on how
to use this product with steel stud walls contact Customer Service and ask about the SSMK1 steel stud mounting kit.

If you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this product, contact
manufacturer Customer Service or call a qualifi ed contractor.

Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

Required Tools

Supplied Parts and Hardware
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged
item to your dealer; contact Customer Service. Never use damaged parts! NOTE: M4, M6, or M8 describes the diameter, mm describes the
length of screws that are labeled M# X ##mm. Not all hardware included will be used.
[01] x 1
M7 x 70mm
[04] x 4
M4 x 12mm
[06] x 4
M6 x 40mm
[09] x 4
M4 M6 / M8
M4
[12] x 4 [13] x 4
6901-002029 10
English
36 kg (80 lb) includes TV and any accessories
[02] x 2
M4 x 30mm
[07] x 4
M8 x 16mm
[10] x 4
5mm
10mm
(3/16 in.)
(3/8 in.)
[05] x 4
M6 x 14mm
[08] x 4
M8 x 40mm
14mm
[14] x 4 [15] x 4
[03] x 1
[11] x 4
24mm
[16] x 4
3
