26 screw hole
27 screw
28 bracket
29 fixing hole
30 wall plate
31 ball joint
32 screw
33 wall plug
34 battery compartment
35 LED jumper
36 ZONE jumper
Door/window contact 3000M (see Fig. E)
37 sensor
38 LED
39 arrow marks
40 magnet
41 adhesive pad
42 ZONE jumper
43 battery compartment

5. Technical data

Siren 3000IS
Operating voltage
Current consumption
Wireless frequency
Wireless components
Sound pressure level
Operating temperature
PIR-detector 3000P
Operating voltage
Current consumption
Power supply
Wireless frequency
Wireless range
Detection area
Operating temperature
Door/window contact 3000M
Operating voltage
Current consumption
Power supply
Wireless frequency
Wireless range
Operating temperature
Remote control 3000R
Operating voltage
26
12 V DC (mains adapter)
max. 200 mA
433 MHz
max. 5 remote controls und max. 20
detectors enrollable
approx. 100 dB(A) / 1 m
±0° C to + 40° C
3 V DC
max. 10 mA
2x 1,5 V AA alkaline batteries (LR6)
433 MHz
max. 30 m (in free space)
approx 8 m through 110°
±0° C to + 40° C
1,5 V DC
max. 40 mA
1x 1,5 V AA alkaline battery (LR6)
433 MHz
max. 30 m (in free space)
±0° C to + 40° C
3 V DC
Current consumption
Power supply
Wireless frequency
Wireless range
Operating temperature
Mains adapter
Input voltage
Output voltage

6. Safety instructions

The following instructions are provided for your safety and satisfaction during
operation of the product. Note that non-observance of these safety
instructions results in significant risks of accident.
Danger! If this point is not heeded, life and health are endangered.
! Do not leave small children unsupervised with the product, packaging
material or small parts. Otherwise there is a risk of fatal injury due to
choking!
! Ensure that the alarm siren is not activated when persons are close to the
siren. Wear ear protection when testing the unit, otherwise there is a
danger of hearing damage.
! Do not damage any gas, electricity, water or telecommunication lines
during drilling and fixing work. Otherwise there are dangers of personal
and fatal injury!
! Treat the supply lines carefully. Lay these so that they cannot be
damaged and do not present any tripping hazard. Fix the cables
sufficiently. Do not pull the cables over sharp edges and do not crush or
crimp them elsewhere. Otherwise there are dangers of personal and
fatal injury!
! Use only the supplied mains adapter with the siren. Before connecting
the power supply to the mains, ensure that the mains current complies
with 230 V ~, 50 Hz and is fitted with a fuse according to regulations.
Otherwise there are dangers of fire and fatal injury.
! Do not allow the product to contact with moisture. Never immerse the
product in water. Otherwise there is danger of fatal injury!
! Ensure that the batteries are not short circuited or exposed to fire. The
batteries must not be opened or recharged. Otherwise there is a risk of
fatal injury due to explosion!
! Leaking or damaged batteries can cause burns by contact with skin.
Handle these using suitable protective gloves.
Attention! Non-observance of these instructions puts property at risk
of damage.
! Before installing and operating the product check the package for
damages and completeness.
! Do not connect any damaged device (e.g. transport damage) and
disconnect the power supply immediately in the case of damage.
! Unplug the mains adapter from the mains socket. Arrange for the
damage to be repaired immediately by a specialist!
max. 70 mA
1x 3 V CR2025
433 MHz
max. 30 m (in free space)
-10° C to + 40° C
230 V ~ 50 Hz
12 V DC , 500 mA
