SAFETY
INFORMATION
To avoid personal injury or property damage during system operation, read and follow
all
ENERPAC CANNOT BE RESPONSIBLE FOR DAMAGE OR INJURY RESULTING FROM UNSAFE
USE OF PRODUCT, LACK OF MAINTENANCE, OR INCORRECT PRODUCT AND SYSTEM
APPLICATION.

SPECIFICATIONS

INSTALLATION

Battery Pack
Slide the BP1724 battery pack into the battery compartment until it latches into place.
Illustration 1 on page 4 shows the proper installation of the battery pack.
To remove the battery pack, press battery inward while pushing down on the battery
release latch (A). The battery will eject far enough to grasp and pull out.
, and
CAUTIONS, WARNINGS
Contact Enerpac when in doubt as to applications and safety precautions.
WARNING
To avoid personal injury, always wear proper personal protective gear
when operating hydraulic equipment.
WARNING
The system operating pressure must not exceed the pressure
rating of the lowest rated component in the system.
WARNING
Make sure that all system components are protected from external
sources of damage, such as excessive heat, flame, moving
machine parts, sharp edges, and corrosive chemicals.
CAUTION
Carry the pump by the handle or the strap. Carrying or dragging
the pump by the hose can damage the hose and/or the pump.
Flow at 0 psi [0 bar]
Flow at 10,000 psi [700 bar]
Usable Oil Capacity
Voltage
Weight
LED Status
CAUTION
The battery can be inserted only in the proper direction. Do not force
the battery into the compartment.
IMPORTANT: Remove the battery from the pump when the pump is not in
use. Storing the battery in the pump will cause the battery to discharge rapidly.
To protect the life of the battery, store the battery pack in the charger.
included with or attached to each product.
INSTRUCTIONS
3
16 in /m [262 cm
3
10 in /m [164 cm
3
38 in [662 cm
24 VDC
18.5 lbs. [8.4 kg]
Flashing Low Battery
Steady On Fault
3
3
/m]
3
/m]
3
]
