MIDI Implementation
Detailed MIDI Implementation
2 ports of 16 channels are provided for a total of 32 channels.
MIDI Message
HEX Code
NOTE ON
9nH kk vv
NOTE OFF
8nH kk vv
PITCH BEND
EnH bl bh
PROGRAM CHANGE CnH pp
CHANNEL
DnH vv
AFTERTOUCH
CTRL 00
BnH 00H cc
CTRL 01
BnH 01H cc
CTRL 05
BnH 05H cc
CTRL 06
BnH 06H cc
CTRL 07
BnH 07H cc
CTRL 10
BnH 0AH cc
CTRL 11
BnH 0BH cc
CTRL 64
BnH 40H cc
CTRL 65
BnH 41H cc
CTRL 66
BnH 42H cc
CTRL 67
BnH 43H cc
CTRL 71
BnH 47H cc
CTRL 72
BnH 48H cc
CTRL 73
BnH 49H cc
CTRL 74
BnH 4AH cc
CTRL 75
BnH 4BH cc
CTRL 76
BnH 4CH cc
CTRL 77
BnH 4DH cc
CTRL 78
BnH 4EH cc
CTRL 84
BnH 54H vv
CTRL 91
BnH 5BH vv
CTRL 93
BnH 5DH vv
CTRL 94
BnH 5EH vv
CTRL 98
BnH 62H vv
CTRL 99
BnH 63H vv
CTRL 100
BnH 64H vv
CTRL 101
BnH 65H vv
CTRL 120
BnH 78H 00H
CTRL 121
BnH 79H 00H
CTRL 123
BnH 7BH 00H
CTRL 126
BnH 7EH 00H
CTRL 127
BnH 7FH 00H
CTRL CC1
BnH ccH vvH
CTRL CC2
BnH ccH vvH
RPN 0000H
BnH 65H 00H 64H 00H
06H vv
RPN 0001H
BnH 65H 00H 64H 01H
06H vv
RPN 0002H
BnH 65H 00H 64H 02H
06H vv
NRPN 0108H
BnH 63H 01H 62H 08H
06H vv
NRPN 0109H
BnH 63H 01H 62H 09H
06H vv
NRPN 010AH
BnN 63H 01H 62H 0AH Vibrate delay modify (vv=40H -> no modif)
60
Description
Midi channel n(0-15) note ON #kk(1-127), velocity vv(1-127). vv=0
means NOTE OFF
Midi channel n(0-15) note OFF #kk(1-127), vv is don't care.
Pitch bend as specified by bh|bl (14 bits)
Maximum swing is +/- 1 tone (power-up). Can be changed using « pitch
bend sensitivity ». Center position is 00H 40H.
Program (patch) change. Specific action on channel 10 (n=9) : select
drumset. Refer to sounds / drumset list. Drumsets can be assigned to
other channels (see SYSEX MIDI channel to part assign and part to
rhythm allocation)
vv pressure value. Effect set using Sys. Ex. 40H 2pH 20H-26H
Bank select : Refer to sounds list. No action on drumset
Modulation wheel. Rate and maximum depth can be set using SYSEX
Portamento time.
Data entry : provides data to RPN and NRPN
Volume (default=100)
Pan (default=64 center)
Expression (default=127)
Sustain (damper) pedal
Portamento ON/OFF
Sostenuto pedal
Soft pedal
TVF Resonnance modify (same as nrpn 0121h)
Env release time modify (same as nrpn 0166h)
Env attack time modify (same as nrpn 0163h)
TVF cutoff freq modify (same as nrpn 0120h)
Env decay time modify (same as nrpn 0164h)
Vibrato rate modify (same as nrpn 0108h)
Vibrato depth modify (same as nrpn 0109h)
Vibrato delay modify (same as nrpn 010Ah)
Portamento control
Reverb send level vv=00H to 7FH
Chorus send level vv=00H to 7FH
Delay send level vv=00H to 7FH
NRPN low
NRPN high
RPN low
RPN high
All sound off (abrupt stop of sound on channel n)
Reset all controllers
All notes off
Mono on
Poly on (default power-up)
Assignable Controller 1. cc=Controller number (0-5Fh), vv=Control
value (0-7Fh). Control number (ccH) can be set on CC1 CONTROLLER
NUMBER (Sys. Ex 40 1x 1F). The resulting effect is determined by CC1
controller function (Sys.Ex. 40 2p 40-4A)
Assignable Controller 2. cc=Controller number (00h-5Fh), vv=control
value (0-7Fh). Control number can be set on CC2 CONTROLLER
NUMBER (Sys.Ex. 40 1x 20). The resulting effect is determined by CC2
controller function (Sys.Ex.40 2p 50-5A).
Pitch bend sensitivity in semitones (default=2)
Fine tuning in cents (vv=00 -100, vv=40H 0, vv=7FH +100
Coarse tuning in half-tones (vv=00 -64, vv=40H 0, vv=7FH +64
Vibrate rate modify (vv=40H -> no modif)
Vibrate depth modify (vv=40H -> no modif)
