Troubleshooting - concept 2 PM3 Gebrauchsanweisung

Notes:
1) Remove batteries or battery pack from the PM3 or PM4
if monitor will not be used for a period of four months or
more.
Safety Information for PM4 Rechargeable Battery Pack
Do not:
• Open the plastic case
• Drop the battery pack
• Allow battery pack pins to touch each
other or any metal object
• Use if damaged or leaking
• Trash, incinerate, crush, etc.
WARNING: If batteries leak, do not use them. Battery fluids are corrosive and can damage eyes, irritate skin, etc.
If contact occurs, wash affected area immediately and thoroughly with water.
MISCELLANEOUS
Cleaning the PM
Use a cloth lightly dampened with water only. Do not spray with a cleaner or leave in the rain.
Formulas Used
Watts = 2.80/(sec/meter)^3
Calories/Hour = Kcal/hr = (watts) x (4) x (0.8604) + 300
Bottom View of PM
Port for the optional USB port for connecting to a computer. Beveled
Polar™ heart rate
corners on USB cable plug face the back of the
receiver.
monitor. DO NOT FORCE when plugging in.
See concept2.com/pm for current information.

TROUBLESHOOTING

1. If the PM malfunctions or does not "wake up," reset PM:
• Insert a pen/pencil tip into the reset hole on the back and press lightly.
• Remove the batteries for 30 minutes and insert two new alkaline D-Cell (LR20) batteries.
2. To change language: press [MENU/BACK] until screen stops changing. Press fifth grey button on right, then press second
grey button on right twice, and select your language. Alternately, hold down CHANGE UNITS and CHANGE DISPLAY and reset
monitor. You can then select your desired language. (Note: This procedure will reset PM to factory settings.)
3. If your computer does not recognize that your PM3/PM4 is connected to it try one of the following:
• Use another computer and/or USB cable.
• Remove batteries and USB cable for 30 minutes then reinsert batteries and try again.
Refer to concept2.com/pm for more information and software updates.
Battery compartment: Loosen screw and press
thumbstrike in direction shown to open.
Do:
• Use only in a PM4; if not used in PM4, store carefully so pins are not shorted
• Keep clean and dry
• Use between 0˚ and 40˚ C
• Charge (row or plug PM4 into USB) after prolonged period of non-use
• Keep battery pack away from children
• Recycle properly
Flywheel sensor cable must be connected
here for the PM to operate.
Back View of PM
PM4
6
PM3
PM4
PM3
Race system jacks
Battery cover
Reset here
