4.3 Setting the analog output, switching output, and other sensor configurations via
the menu
Figure 3: K
8020032.ZX33 | SICK
Subject to change without notice
Q (PNP)
1
0
L
D 1
0
Q (NPN)
1
L
0
1
D
0
Figure 2: C
As an alternative, the analog and switching output can also be set via the menu. Fur‐
ther sensor configurations can also be performed via the menu. The menu is accessed
by briefly pressing the Set button for < 1 s. Graphic K describes how to navigate within
the menu.
