■ Pull the starter grip a quick firm and consistent upward
motion (no more than 4 times).
■ Set the choke lever to the
■ Pull the starter grip with a quick firm and consistent
upward motion (no more than 6 times) until engine
starts.
■ Allow engine to warm up for 6~10 seconds in the
choke position.
■ Set the choke lever to the
the trigger to run.
For RBC430SBSD
■ Lay the trimmer on a flat, bare surface.
■ Press the primer bulb 10 times.
■ Set the choke lever to the
■ Hold down the throttle lock and then squeeze
the throttle trigger. Lock the throttle in position by
depressing the throttle interlock button.
■ Pull the starter grip with a quick firm and consistent
upward motion (no more than 4 times).
■ Set the choke lever to the
■ Pull the starter grip with a quick firm and consistent
upward motion (no more than 6 times) until engine
starts.
■ Allow engine to warm up for 6~10 seconds in the
choke position.
■ Set the choke lever to the
the trigger to run.
Please make sure the choke lever in
squeezing the trigger to run.
If the engine stalls, set the choke lever to the
Then pull starter rope until the unit starts.
To start a warm engine:
See fi gure 9b.
Make sure there is fuel visible in the primer bulb, if not,
follow cold start procedure.
Make sure choke lever is set to
Pull the rope quickly and sharply straight up until the
engine starts.
To stop the engine:
Place the ignition switch to "O" (off) position.

OPERATING THE TRIMMER

See fi gure 7.
WARNING
Always position the unit on the operator's right side. The
use of the unit on the operator's left side will expose
the user to hot surfaces and can result in possible burn
injury.
English (Original instructions)
choke position.
position, then squeeze
choke position.
choke position.
position, then squeeze
position before
position.
position.
24
WARNING
To avoid burns from hot surfaces, never operate unit
with the bottom of the engine above waist level.
RBC430SESD: Hold the product with the right hand on the
rear handle and the left hand on the front handle.
RBC430SBSD: Hold the product with the right hand on
the trigger handle and the left hand on the left handle.
Keep a fi rm grip with both hands while in operation. The
product should be held at a comfortable position with the
trigger hand or rear handle about hip height.
Always operate the product at full throttle. Prolonged
cutting at partial throttle will result in lubricant dripping
from the silencer. Cut tall grass from the top down.
This will prevent grass from wrapping around the shaft
housing and string head which may cause damage from
overheating. If grass becomes wrapped around the string
head, stop the engine, and remove the grass.

CUTTING TIPS

See fi gure 7.
■ Do not push into the grass to be cut. Move from side to
side, moving forward a little at the end of each sweep.
■ Keep the product tilted towards the area being cut.
■ Do not cut in dangerous cutting area.
■ Use the tip of string to do the cutting; do not force
string head into uncut grass.
■ Wire and picket fences cause extra string wear, even
breakage. Stone and brick walls, kerbs and wood may
wear string rapidly.
■ Avoid trees and shrubs. Tree bark, wood mouldings,
cladding and fence posts can easily be damaged by
the string.
ADVANCING THE LINE
Line advance is controlled by tapping the string head on
grass while running engine at full throttle.
■ Run engine at full throttle.
■ Tap the knob on ground to advance string. The string
advances each time the knob is tapped. Do not hold
the knob on the ground.
■ The string should advance until it is cut to length by
the line cutting blade located on the cutting attachment
guard.
OPERATING THE BRUSHCUTTER
See fi gure 8.
RBC430SESD
Hold the brushcutter with your right hand on the rear
handle and your left hand on the front handle.
RBC430SBSD
Hold the brushcutter with the right hand on the trigger
handle and the left hand on the left handle.
