23. Power head (upper shaft)
24. Position hole
25. Hole on the hanger cap to fi t lock button of lower
booms.
26. Hanger cap
27. Hole on lower attachment
28. Clamp
29. Screw/bolt
30. Bracket (RBC430SBSD only)
31. Gear case assembly
32. Holding pin
33. Mounting bracket
34. Combination wrench
35. Cupped washer
36. Blade retainer nut
37. Trimmer line cut-off blade
38. Full choke position
38b. Half choke position
39. Run position
40. Blade protector
41a. Quick release tap
41b. Latch
42. Filter
43. Air filter cover
44. Oil cap/dipstick
45. Hatched area
46. Top cover
47. Screw
48. Spark plug
49. String head cover
50. Latches
51. Bump/Feed knob
52. Hex bolt
53. Spool
54. Spring
55. String head housing
56. Latch opening
57. Direction of cutter rotation
58. Best cutting area
59. Dangerous cutting area
60. Upper flange washer
61. Drive connector
ASSEMBLY

UNPACKING

This product requires assembly.
■
Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
■
Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
■
Do not discard the packing material until you have
English (Original instructions)

PACKING LIST

If any parts are damaged or missing, do not operate the
product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
Do not attempt to modify the product or create
accessories not recommended for use with the product.
Any such alteration or modifi cation is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
INSTALLING THE POWER HEAD SHAFT TO THE
ATTACHMENT
See figure 2.
Never install, remove, or adjust any attachment while
power head is running. Failure to stop the engine can
cause serious personal injury.
The attachment connects to the power head shaft by
means of a coupler device.
■ Loosen the knob on the coupler of the power head
■ Push in the button located on the attachment shaft.
20
carefully inspected and satisfactorily operated the
product.
● Power head with upper boom assembly
● Lower boom with string head assembly
● Front handle assembly (RBC430SESD only)
● Blade guard
● Grass deflector
● Blade with cover
● Shoulder strap
● Manual
● Figure sheet
● Nut
● Washer
● Engine oil
● Combination wrench
● Holding pin
WARNING
WARNING
WARNING
shaft and remove the end cap from the attachment.
Align the button with the guide recess on the power
head coupler and slide the two shafts together. Rotate
the attachment shaft until the button locks into the
positioning hole.
