It is the responsibility of the installer/owner to ascertain
compliance with specific local regulations prior to installa-
tion.
Jacuzzi Europe S.p.A. gives no guarantee in this respect and
refuses all responsibility regarding compliance of the instal-
lation carried out.

Technical Features

The Premium spas feature a single-phase power supply (220-
240 V). All electro-mechanical parts and pipes are enclosed.
The J-210/215/225 are equipped with 1 two-speed pump, whilst
the J-235/245/275/280 are equipped with 2 pumps.
Maximum absorption of the system
The electrical system that powers the spa must absolutely be
sized for maximum consumption (as shown in the table).
Power supply
Model
(single-phase)
Volt
J-210
220-240 ~
J-215
220-240 ~
J-225
220-240 ~
J-235
220-240 ~
J-245
220-240 ~
J-275
220-240 ~
J-280
220-240 ~
(k): a 230V
(single-phase)
(j): max. power
absorption
If sufficient electrical energy is not available, an electronic
energy consumption limiter can be activated from inside the
electronics box (refer to the relative installation / user and main-
tenance manual).
This operation can only be performed by authorized Jacuzzi®
technicians and limits electricity consumption as follows:
J-210/J-215/J-225
- alternative consumption: 3.5 kW (when the pump is run at high
speed, the electric heater goes off). This is the factory default set-
ting.
J-235/J-245/J-275 /J-280
- medium alternative consumption: 5.3 kW (when two pumps are
run at high speed, the electric heater goes off; pump 2 only operates
at high speed).
- minimum alternative consumption: 3.5 kW (when one pump is
run at high speed, the electric heater goes off; pump 2 only operates
at high speed). This is the factory default setting.
Tot. Consumption
electric heater + pump(s)
Hertz Ampere
(k)
50 21
(k)
50 21
(k)
50 21
(k)
50 29
(k)
50 29
(k)
50 29
(k)
50 29
Weights
net weight
Model
kg
J-210 ~ 239
J-215
~ 223
J-225
~ 255
J-235
~ 326
J-245
~ 375
J-275
~ 366
J-280
~ 401
(s): standard base;
(p): ABS (plastic) pan;
User safety
The system, if installed by qualified personnel, does not pres-
ent any hazard for the user. Safety is however also contingent
upon proper use, as set forth by the user's manual included with
kW
the product. The user must contact qualified personnel for spe-
(j)
4,8
cial operations described in the manual.
(j)
4,8
It is important to make sure that personnel tasked to install
(j)
4,8
and manage the system are qualified as per legal requirements
(j)
6,7
in effect in the country where installation is carried out.
(j)
6,7
(j)
6,7
This appliance uses and generates radio waves: if it is not in-
(j)
6,7
stalled and used as directed, it may cause interference with the
reception of radio and television programs.
However, in special cases this may happen even if the directions
provided are followed.
Set up for installation
The site where the hot tub will be installed must be de-
signed to ensure the possible removal and relocation of
the hot tub itself, if necessary.
Position the hot tub away from glass and/or reflective sur-
faces in order to avoid possible damage to its panelling.
The customer must make provisions for a ground drainage point
8) of suitable dimensions and that can be inspected for any
(
cleaning that may be required.
ATTENTION: Before preparing the drainage system
for connecting the hot tub, consult the local author-
ities about regulations for the disposal of chemical-
ly-treated water.
Premium spas are equipped with the drain arranged as in
1-7, part.A/A1 and
According to the type of installation chosen the ground drain-
age point will then be put into position. The Premium spas can
be installed in a variety of ways:
- Free standing on the floor or on a specifically prepared base
( 9).
16
average fill maximum water total
volume max. weight
litres litres kg
~ 908 ~ 1173 ~ 1412
~ 833 ~ 1037 ~ 1260
~ 1340 ~ 1658 ~ 1913
~ 1363 ~ 1741 ~ 2067 ~ 4,39
~ 1363 ~ 1779 ~ 2154
~ 1590 ~ 2006 ~ 2372
~ 1741 ~ 2158 ~ 2558
8.
support area load concentrated
on support area
m2 kg/m2
~ 2,68 ~ 525
~ 3,1 ~ 408
~ 3,96 ~ 483
(s) (p) (s) (p)
/ ~ 4 ~ 471 / ~ 516
~ 4,39 ~ 491
~ 4,96 ~ 478
~ 4,96 ~ 516
