LED Indicators

The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Icon Color
Green
Number Lock (Numeric Keypad) Acti-
Green
Green
Green
Table 1 - LED Status Indicators
6
Description
Hard Disk Activity
vated
Caps Lock Activated
Scroll Lock Activated
Icon Color
The Wireless LAN Module is Pow-
Green
The Bluetooth Module is Powered
Orange
Orange The AC/DC Adapter is Plugged In
Blinking The powered USB Port is on
Orange
Green
Blinking
The Computer is in Sleep Mode
Green
Orange
Green The Battery is Fully Charged
Blinking The Battery Has Reached Critically
Orange
Table 2 - LED Power Indicators
Description
ered On
On
(see page 8)
The Computer is On
The Battery is Charging
Low Power Status
