2 - PRODUCT INTRODUCTION

2.1 - Product description

Halo is an irreversible electromechanical gearmotor suitable for
automating overhead doors up to 14m
16m
. Halo is equipped with an encoder, a control unit and an inte-
2
grated 4-channel receiver. The rail is pre-assembled with a belt, in
one piece or 3 pieces.
A special aluminium rail, powder coated and with integrated LEDs,

2.2 - Composition

The automation system for garage doors is contained in two boxes
forming the automation system's and the rail system's packaging:

2.3 - Models and technical characteristics

CODE
DESCRIPTION
For sectional doors up to 10 sqm (with 3 m rail) or 11 sqm (with 4 m rail), a 24 Vdc motor and a
900HA7
control unit with an integrated receiver and 230Vac power supply
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), a 24 Vdc motor and a
900HA10
control unit with an integrated receiver and 230Vac power supply
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), "Low Energy" with 24 Vdc
900HA10E
motor and a control unit with an integrated receiver and 230Vac power supply
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), a 24 Vdc motor and a
900HA10L
control unit with an integrated receiver and 120Vac power supply
HEAD/RAIL COMPATIBILITY
900RAB3
900RAB3X1
900RAB4
900RAB6
900RAL30
900RAL40
TECHNICAL SPECIFICATIONS
Speed
Force
Max cycles/hour
(1)
Max consecutive cycles/hour
Rated power
Stand-by power
Power supply
Flashing
Courtesy light on rail with integrated LEDs
Accessories power output
Fuse 1 power line
Max no. of transmitters that can be stored
ROLLING CODE
Degree of protection
Use in highly acid, saline or explosive
atmosphere
Dimensions (L x D x H):
Weight
Working temperature
Maximum door size
Maximum door weight
for door up to 2m in height
(1)
and sectional doors up to
2
900HA7
12 cm/s
700 N
20
10
(1)
80W
5,5 W
230Vac (±10%)
50Hz
3 W MAX
-
100mA (24 Vdc NOT
REGULATED)
1AT
90
IP 20
NO
235-330-84 mm
6,7 Kg
-10°C/+45°C
11 m
2
90 Kg
allows for garage lighting both during movement and at any other
time.
The special flat design of the motor housing also makes it possible
to install it less invasively near the door cross beam or the spring
holder shaft.
FIG. 1
head package contents with parts list
FIG. 2
LED rail
FIG. 3
single piece steel rail
FIG. 4
3-piece steel rail
HA7
X
X
X
900HA10
900HA10E
12 cm/s
12 cm/s
1000 N
1000 N
20
20
10
10
100W
100W
5,5 W
<0,5 W
230Vac (±10%)
230Vac (±10%)
50Hz
50Hz
3 W MAX
3 W MAX
20 W MAX
20 W MAX
100mA (24 Vdc NOT
100mA (24 Vdc NOT
REGULATED)
REGULATED)
1AT
1AT
90
90
IP 20
IP 20
NO
NO
235-330-84 mm
235-330-84 mm
6,7 Kg
6,7 Kg
-10°C/+45°C
-10°C/+45°C
16 m
16 m
2
130 Kg
130 Kg
POWER
700N
1000N
1000N
1000N
HA10 - HA10E - HA10L
X
X
X
X
X
X
900HA10L
12 cm/s
1000 N
20
10
100W
5,5 W
120Vac (±10%)
50/60Hz
3 W MAX
20 W MAX
100mA (24 Vdc NOT
REGULATED)
2AT
90
IP 20
NO
235-330-84 mm
6,7 Kg
-10°C/+45°C
16 m
2
2
130 Kg
EN
5
