The door must perform a slow-speed opening
ATTENTION !
4
If the door closes, press the button again to stop it then press it again to reverse the direction. This procedure can only
be successful if the first operation is an opening stroke and it ends with the slider impacting the mechanical stop previ-
ously positioned
The door reaches full opening position as the slider reaches its mechanical stop, stops for a second and then restarts in the closing
5
direction until the operation is complete
6
The values are stored
Perform AT LEAST one second full opening operation and one second full closing operation from the limit stop point without
7
breaks, to allow the control unit to store the motor stress along the travel
If the automation system fails to complete the operation, check that there are no mechanical jams along the travel, the balancing
8
of the door and possibly change and reduce the obstacle sensitivity parameter
To reset opening and closing values:
press and hold the MENU button until the LED L1 lights up and then goes off.
Release the MENU button. LED L1 emits long flashes.
Press the MENU button again upon the:
9
5th flash for the HALO 700 motor
6th flash for the HALO 1000 motor
If the procedure is successful, LED L1 will emit a long flash, otherwise it will flash repeatedly at a fast rate
Repeat the procedure from point 4 above
4.13 - Changing a control unit parameter
If you have a KUBE PRO wireless module, connect it to the control
unit (FIG. 49, 50) and follow the instructions on the screen.
If you have a DYL cable module, connect it to the control unit and
PHASE DESCRIPTION
1
Press the MENU button a number of times corresponding to the parameter to be changed (TAB. 3)
2
LED L1 emits quick flashes followed by a pause corresponding to the parameter to be changed
3
Press and hold down MENU for more than 3 seconds
4
The LED L1 remains off
5
Release the MENU key
The LED L1 will start emitting long flashes, the number of flashes matches the maximum settable parameter value. At the end of
6
the last flash the procedure ends without any parameter change
7
Briefly press the MENU button upon the flash corresponding to the desired parameter value
8
If the procedure is successful, LED L1 will emit a long flash, otherwise it will flash repeatedly at a fast rate
4.14 - Control unit parameter resetting
PHASE DESCRIPTION
1
Press and hold the MENU button until the LED L1 lights up and then goes off
2
Release the MENU key
3
LED L1 will start emitting long flashes
4
Press the MENU button again upon the 3rd flash
5
If the procedure is successful, LED L1 will emit a long flash, otherwise it will flash repeatedly at a fast rate
4.15 - Hole for access control mechanism
Close the garage door (controlled by the motor); using a pencil,
mark the position of the slider on the opposite side with respect to
the door. Release the slider, then drill a 10 mm hole in the centre of
the rail where marked (FIG. 51).
follow the instructions on the screen.
Otherwise proceed as described below:
Check the efficient operation of the mechanism by closing the door
manually, resetting the slider and trying to open the garage door
manually.
EN
11
