Setting the Flow Knob to the Prescribed
Setting
NOTE: For this procedure, refer to FIGURE 4.6.
1. Attach the nasal cannula to the outlet fitting of the
cylinder.
2. Turn the flow knob to the L/min. setting prescribed by
your doctor or therapist.
As changing the L/min. setting on the flow knob will affect
the dose of oxygen delivered, DO NOT readjust the
L/min. setting unless your doctor or therapist instructs
you to.
3. To turn the flow of oxygen Off, turn the flow knob
counter-clockwise to the Off position.
Prescribed Setting
FIGURE 4.6 Setting the Flow Knob to the Prescribed Setting
Part No 1145804
SECTION 4—COMPRESSOR OPERATION
WARNING
29
Outlet Fitting
Flow Knob
HomeFill II Compressor
®
