SECTION 2—INITIAL SETUP
DETAIL "A"
DETAIL "B"
Insert End of
Interconnect
Compressor
Interconnect Hose into
Hose
Inlet/Outlet Fitting
CONCENTRATOR
TOP VIEW
Inlet Fitting
Power
Outlet Fitting
Cord
DETAIL "C"
Inlet/Outlet Fitting
Metal
Tab
FIGURE 2.3 Connecting the Compressor to the Concentrator
HomeFill II Compressor 18 Part No 1145804
®
