Adjustment of Flat Panel Screen
• M10 x 15 mm screws (E) must be securly tightened before changing orientation of wall arm assembly (A). Failure to
lock adapter bracket can cause screen to come off of mount.
FOR PORTRAIT OR LANDSCAPE SCREEN ORIENTATION:
4
from top of tilt head as shown in top view and rear view. Gently grasp sides of screen and rotate screen into portrait
or landscape position as shown in fi gure 4.1 and reinstall rotation block with two M5 x 12 screws.
TILT Adjustment: Adjust tension knob on side of
5
mount to desired tension to enable tilt adjustment and
balance your screen size and weight. Push or pull
from top or bottom of screen to adjust tilt as shown.
The tilt can be adjusted to a maximum of 10° forward
or 5° backward. Retighten tension knob.
ROLL Adjustment:
counter-clockwise, level screen then tighten
M5 x 10 mm screws using
shown in detail 2.
FOR VERTICAL HEIGHT ADJUSTMENT: Tighten or
loosen two M8 x 40 mm screws an equal number of
turns to achieve ± 1" of vertical height adjustment as
shown in detail 2.
CAUTION
• Do not tighten screws with excessive force.
• Be careful not to pinch fi ngers when opening and
closing mount from the wall.
Rotate screen 5° clockwise or
5 mm allen wrench (I)
WARNING
Remove two M5 x 12 mm screws and rotation block
ROTATION BLOCK
M5 X 12 MM SCREWS

TOP VIEW

M5 X 12 MM SCREWS
ROTATION BLOCK

REAR VIEW

as
10 of 46
fi g. 4.1
TENSION KNOB
M5 X 10 MM
SCREWS
M8 X 40 MM
DETAIL 2
SCREWS
ISSUED: 10-30-09 SHEET #: 095-9297-2 12-04-09
