Assembly drawing

2
ATTENTION!
Take care if separating the sensors from the cover immediately after the pump is
switched off as they become hot when in use (approx 60 °C).
4
1. Hose adaptor
1
2. Non-return valve
3. Sensor cover
4. Inlet screen
Figure 5
3
