Error messages

If the battery level is too low, display shows the
battery symbol oppposite.
If the reference needs to be defined, display
shows ERR 0 for 2 seconds, and then keeps on
displaying the two arrows opposite.
During a data transmission through the RS232 interface, ERR1
or ERR2 may appear on display. The first error message means
that a transmitted sign is not allowed, the other that the com-
mand is unknown.

Mounting alternative backs

Undo the 4 tightening screws marked witj A before mounting ei-
ther of the optional backs (see below).
Do not remove the screw marked with B since this screw serves
to protect the
Fig. 1
Fig. 3
sensor.
0,7
6
ERR 0
Fig. 2
Fig. 4
21
