Inserting battery

Insert the battery No. 01961000 as pictured below.
1 Remove the yellow cover.
2 Undo the screw.
3 Pull up the battery compartment.
Replacing the battery causes the indicator to return to the
factory settings.
IMPORTANT: When inserting the battery, check that the
plunger is fully disengaged whilst directed downwards. If
so, the indicator will be reset to zero based on the factory
settings, so that all technical data remain valid. Once this
is done, display looks like the picture shown below.

Switching ON

6
Press any function key
shortly or move the plung-
er to have your indicator
turned ON.
