Models 400-700

Measuring span (mm/in)
Resolution (mm/in)
Max. perm. error (MPE
Repeatability (MPE

Models 400-600 with a 25 mm measuring span

Measuring span (mm/in)
Resolution (mm/in)
Max. perm. error (MPE
Repeatability (MPE
All metrological properties are ensured in upright position
of use, with stable zero (at 0,1 mm from the lower stop)
in both moving directions of the plunger, but also at the
reference temperature of 20° ±1° C.

Clamping the indicator

Every Digico can be clamped over its 8h6 dia. plunger.
If so, the use of components with three tightening faces
is advisable. This avoids any distortion and prevents the
plunger from loosing its metrological properties. Clamping
torque 0,2 N max.
Recommended VKD clamping screw (No. 02611013) and
VKE clamping sleeve (No. 02611014):
20
in mm)
E
in mm)
R
in mm)
E
in mm)
R
12,5 / .5
0,01 / .0005
0,02
0,01
25 / 1
0,01 / .0005
0,02
0,01
12,5 / .5
0,001 / .00005
0,004
0,002
25 / 1
0,001 / .00005
0,005
0,002
