Varian Turbo-V 250 969-9423 Bedienungshandbuch Seite 65

Character ASCII
"A" 41h
CRC -
"B" 42h
CRC -
"C" 43h
CRC -
"D" 44h
CRC -
"E" 45h
CRC -
"F" 46h
CRC -
"G" 47h
CRC -
"H" 48h
"I " 49h
CRC -
"J" 4Ah
CRC -
"K" 4Bh
CRC -
"ACK" 06h
CRC -
"NACK" 15h
CRC -
Answer = after a request from the host, the
Turbo-V 250 controller will answer in one of the following
ways:
•
ACK
•
NACK
•
Message
When the Request is "A, "B", "C", "D", "F", the Turbo-V
250 controller will Answer the ACK or NACK.
Converted ASCII
for CRC calculation
-
BFh
-
BEh
-
BDh
-
BCh
-
BBh
-
BAh
-
B9h
-
-
B7h
-
B6h
-
B5h
-
FAh
-
EBh
When the Request is "E, the Answer will contain the
complete set of the following parameters:
Bytes
1
MSB LSB
- - - - X X X X
0
1
2
3
4, 5 = HIGH LOAD
6
7
2÷5 Cycle Time
Pump Life
6÷9
10÷11 Pump Temperature
12 Current*
13 Voltage*
Frequency
14÷17
18÷19 Cycle #
20 R1 Status
21 R2 Status
22 CRC
*The values for current and voltage are given as
numbers, scaled from 0 to 255, where 0 corresponds to
0 V and 255 to the full scale voltage (100 V) or current
(2.5 A).
When the Request is "G", the Answer will contain a
string of 11 characters with the following parameters:
Bytes
1-2 Pump cycles number (integer coded
in 2 bytes)
3 Speed threshold
4-7 Run up time in seconds
(long coded in 4 bytes)
8 Deat time
(0 = NO 1 = YES)
9 Controller OFF when R2 OFF
(0 = NO 1=YES)
10 Soft Start Mode
(0 = NO 1=YES)
11 CRC
When the configuration parameters have to be changed,
send a Request string with 9 characters of the following
type:
"H" + .... data .... + CRC
58
TECHNICAL INFORMATION
Meaning
= STOP
= WAITING INTERLOCK
= STARTING
= NORMAL OPERATION
= FAILURE
= APPROACHING LOW SPEED
Meaning
