APPLICATION AREA

3.1

Control and indication of flow rates in piping

Setpoint
Flow rate sensor
Fig.: Structure of a control system with the compact flow controller type 8623-2
(schematic)
6 - 8623-2 Standard
actual value (2-1000 Hz)
controlled
flow
Controller Type 8623-2
proportional valve
