A 2 . Manually With Water Temperature Monitoring - Jaga DBH SET Bedienungsanleitung

MODE
Speed 1
Blue LEDs are flashing in the set mode: the water temperature of the supplied water is too high (Tw > 24 ̊ C ).
Red LEDs are flashing in the set mode: the water temperature of the supplied water is too low (Tw < 28 ̊ C ).
A1.2. OPTION : THERMO-ELECTRICAL MOTOR
– Valve opens in heating and cooling mode.
– Valve closed in off mode.
A 2 . MANUALLY WITH WATER TEMPERATURE MONITORING
Configuration code : DPC.HC4120 / DPC.HC4220 / DPC.HC4423 / DPC.HC4523
MODE
ONLY DPC.HC4423 /
DPC.HC4523
Option:
Thermo-electrical motor
A2.1. FACTORY SETTINGS
A2.1.1. Without control panel
The unit is controlled by the water temperature The unit starts as soon as the set water temperature
has been reached.
The unit starts as soon as the water temperature > 28 ̊ C .
Only with configuration code DPC.HC4220!
The unit starts as soon as the water temperature < 24 ̊ C .
1 Speed . Activator speed is set according to the unit's length.
MODE
Speed 2
1
- DPC.HC4120 / DPC.HC4220
MODE
Speed 3
[4]
Option
EN
91
