A/V & Data In/Out
TV SCART
VCR SCART
AUDIO R/L
RS-232C

Power Supply

Input Voltage
Type
Power Consumption
Standby Power
Protection
Physical Specification
Size (W x H x D)
Weight (Net)
Operating Temp
Storage Temp
Storage Humidity
You can use a special antenna switch with DiSEqC commands.
•
When changing ASTRA1 to EUTELSAT for example, a DiSEqC command is sent
with the 22KHz tone through the antenna cable. The antenna switch will change
ASTRA1 to EUTELSAT. The concept of DiSEqC is a protective trademark of
EUTELSAT.
Data rate decides the picture quality of digital TV programmes.
•
Data rate of about 5-6 Mbit/s coincides with the picture quality of a analog
TV programme.
Video Output(CVBS, S-Video, RGB)
Audio Output
(Resolution : 20 bits DAC, Max. 2 Vrms)
Video Output(CVBS)
Video Input(CVBS, S-Video, RGB)
Audio Output(Resolution : 20 bits DAC, Max. 1 Vrms)
RCA/Cinch Volume and Mute Control
(Resolution : 20 bits DAC, Max. 2 Vrms)
Transfer rate 115,200 bps, 9pin D-sub Type
190 - 250V AC, 50/60 Hz
SMPS
Max. 30W
≤
8W
Separate internal fuse. The input shall have lightening Protection
260 x 50 x 180 mm
Around 1.3 kg
0°C to + 45°C
-10°C to + 70°C
5% ~ 95% RH (Non-Condensing)
E40
