Motorised System
8. You should move the motor as far west as possible and the move it east so that you cover the
complete movement range of the motor.
9. During the move from west to east the Signal Quality bar should register a signal once.
This is the position of the satellite. If there are two or more different positions which registers a
signal, then you must choose another frequency that is unique to the satellite you want.
10. Use the Signal level and Strength Quality bar at the bottom of the screen to judge the best
position of the dish.
11. Use the
12. When you have the best position of the dish go to the Motor Control option and using the
buttons select store and press the
13. If you do not store this position, it will be lost when you exit the menu.
14. Repeat the process for each satellite if required, remembering to use a different antenna
alternative for each satellite.
5. Moving to a pre-set satellite
Once you have stored the positions of the satellites you want (see left below) you can now search for
the services transmitted from them. Before you can do this, you must move the motor to the
position of the satellite you wish to search. To do this, you must access the Satellite Settings menu.
Do as follows ;
1. Select Service Searching from the Main Menu and press the
Searching menu.
2. Select the Manual Search option and press the
3. Select the Antenna Alternative option and press the
menu.
4. In the Satellite Settings menu ensure that you have DiSEqC Command Mode option set to User.
5. Highlight the option Satellite Name and use the
to view.
6. When you have selected the satellite you wish to view, go down to the Motor Control option and
again using the
7. The motor will now move to the position of the selected satellite.
8. The Movement option is used to fine-tune the position of the motor.
9. When using the Movement option for fine-tuning, you must remember to store the changes you
have made or else these will be lost.
E33
buttons to stop the motor when required.
buttons select go to and press the
button. The position of the satellite should now be stored.
button, to display the Manual Search menu.
button, to display the Satellite Settings
buttons to select the satellite you want
button.
button, to display the Service
