Motorised System

DiSEqC 1.2 User Instructions
If you have a DiSEqC 1.2 motorised system, then you can use the DiSEqC 1.2 functions available.
The following instruction describes how to use the DiSEqC 1.2 functions to store the positions of the
satellites and to search for the services(STAB Rotor Sat motor recommended).
1. Satellite Setting Menu Options
When DiSEqC Motorised System is Enabled in the Antenna Setting, a new menu is available for
configuring the motor. This menu is called Satellite Setting and is accessed by pressing the
button while the option Antenna Alternative is highlighted in the Manual Search menu.
The following options are available on the Satellite Setting menu.
Satellite Name
A selection of satellite names that can be used to identify a motor position. If the satellite name you
require is not available, please use other. In installer mode the Satellite Name Reference refers to the
0 position of the motor.
Movement
In user mode this is used to fine-tune the position of the motor for better reception.
In Installer mode this is used to search for the position of a satellite manually.
Motor Control
• Search : Searches for services on the chosen transponder.
• Goto : Moves the motor to the stored position of the selected satellite name.
• Store : Stores the current position of the motor for the selected satellite name.
• Reset : Resets all stored positions of the motor relative to the 0 position.(Installer mode only)
DiSEqC Command Mode
Changes the current mode between Installer and User.
2. Setting your Receiver for DiSEqC 1.2
You must set your receiver up so that it is ready to use DiSEqC 1.2. To do so, do as follows
8. The option DiSEqC Input Selection should now be disabled. This option is used for DiSEqC 1.0
and cannot be used in conjunction with DiSEqC 1.2. Your receiver is now ready to use
DiSEqC 1.2. To return to the Main Menu, use the
E31
1. Press the Menu( )button, to display the Main Menu.
2. Select Service Searching option and press
to display the Service Searching menu.
3. Select Antenna Setting option and press
to display the Antenna Setting menu.
4. You must set up a separate antenna alternative for each
satellite position required.
5. Select the name of the satellite you wish to use.
6. Select the correct LNB frequency for the LNB you are using.
7. Set the Motorised System to Enable using the
button until you are at the Main menu.
button,
button,
buttons.
