BEFORE USE

ATTENTION! Make sure that the device is disconnected from mains.
 Disengage the clamps (B5) (drawing 1). Lift an engine's set using an attached handle and take
out a water filter tank (B2) (drawing 2).
 Next take accessories out and put them in a handle (D1).
 While unpacking check if there are all parts and if they are not damaged.
 Make sure that a foam filter (A7) is located in float chamber (A6).
 Put wheels (B7) on a bottom part of water container (B1) (drawing 3).
 Fix water filter tube (B4) (drawing 4), through rubber gasket (B8) (drawing 5).
 Next put water filter tank (B2) into water container (B1) (drawing 6).
 Put into the tank (B2), water filter sponges (B3) (drawing 7, 8).
 Put engine's set on the container and fix using clamps (B5) (drawing 9, 10).

DIRECTIONS FOR USE

DRY CLEANING
To ensure the highest comfort and safety a vacuum cleaner has been equipped with a water
filter. It is a specially designed device whose role is to absorb the tiniest particles of dust and
dust mites with the use of physical properties of water. Principle of water filter operation is
that the air sucked into the vacuum cleaner goes through a water container, leaving all dust
and dust mites in it.
1. Make sure that the device is disconnected from mains.
2. Check if the container, tubes and a hose are dry and without any dirt.
3. Disengage clamps and lift the engine's set using a handle.
4. Take off water filter tank and fill in the container with clean water (max. 2l) (drawing 15). Put
the water filter tank on.
5. Put an engine's set back on the device and lock the clamps.
6. Connect a sucking hose (C1) (drawing 11), using a connecting element (C4) of sucking inlet of
the vacuum cleaner (B6). Additional accessories can be attached to telescopic sucking tube
(C5) or directly to a handle (C2) depending on what you are going to do.
7. Connect the device to the mains.
8. Use a switch (A1) to switch a vacuum cleaner on.
9. To ensure freshness of air in the room add some drops of freshener (D5) to water in the con-
tainer (B1).
Using the equipment described above you can clean:
10. Floor and carpet head (C7) used to remove dust from carpets, rugs and hard floor surfaces. It
is equipped with rings allowing easier handling and a button. After pressing the button you
can adjust the head for hoovering hard surfaces, for example floors, parquets.
11. Attachment for cracks (D2) is used to clean places that are not easily accessible.
12. Telescopic sucking tube (C5) is used to suck earth, chips, crumbs and fur.
13. Venetian blinds cleaner brush (D4) and round brush (D3) can be used to remove dust from
shelves, books, lampshades, frames, decorations, curtains etc.
