Technical Information
Examples
Auto Test Phase:
In stop status, it is possible to take the three phase test diagnosis
pressing the COUNTERS + MEASURES + LOW SPEED buttons at the
same time for at least 2 sec.
This test checks the motor windings electrical continuity and
symmetry. Furthermore it is able to detect a short circuit between a
motor phase winding and the Protection Earth.
S /S
TART TOP
C M
OUNTERS EASURES
L
OW SPEED
