DESCRIPTION OF THE CONNECTION BOXES

9.1. DOCK M_USB2 AND DOCK M_VIDEO POWER SUPPLY
SOPROLIFE power supply is connected to the power outlet. The other end of the cord is connected to the
connection box where the symbol 6 V is located (PHIHONG, PSA 10R-060 Model or FRIWO, MPP15 FW
7555M/06 model).
The power supply automatically adapts to the electric networks 115 V~ - 230 V~; 60 Hz - 50 Hz; 0.5 A. SOPROLIFE
voltage is powered by 6V of a continuous low voltage type..
9.2. DOCK MU_USB2 / DOCK MU_VIDEO POWER SUPPLY
The electrical connection of this connection box should be performed by the installer. SOPROLIFE power supply
is performed through the connection box that should be connected 24 V~; 50 Hz - 60 Hz; 10 VA.
9.3. DOCK USB2 POWER SUPPLY
The dental camera electrical supply is directly performed through the computer USB port. The voltage powering
the camera is of continuous 5 V low voltage type (0.5 A).
9.4. VIDEO AND USB OUTPUTS
These connection boxes has two independent video outputs* - a composite one and a Y/C "S-Video" one.
One of these two outputs should be connected to the monitor video input (preferably Y/C "S-Video"). This
connection box has a digital USB 2.0 output that can be connected to a computer USB2 port.
*Except on Dock USB2.

9.5. FOOTSWITCH

The footswitch should be connected here .if you have selected it to freeze the image.
