5. ASSEMBLY INSTRUCTIONS

Take all parts out of the packaging carefully and place them on a flat surface. When doing this,
use suitable padding to protect the working surface. Assembly of the individual parts should
be carried out by 2 people!
Before assembly, check the parts list to verify that all parts are present. Some parts have already
been pre-assembled to simplify the assembly process for you.
STEP 1
