When using the display cabinet, as well as during maintenance works, pay attention not to destroy the
temperature sensor in the evaporator screen!
(This concerns the "Wiktoria" device) In order to clean the conden-
ser it is essential to remove the front glass of the device.
(This concerns the "Wiktoria2" device) In order to clean the con-
denser it is necessary to unscrew the sheet metal screw and re-
move the wind brace.
It is essential to keep the condenser of the device clean. Dirt may
hinder the heat exchange, causing mainly increase in electric ener-
gy consumption and may cause damage of aggregate compressor.
Clean condenser lamellas with help of soft brush or paint brush. If
the condenser is extremely dirty (blocked lamellas) it is indicated
to use vacuum cleaner or compressed nitrogen to suck / blow the
dirt from between lamellas.
The producer shall not be held responsible for damages of the condenser aggregate resulting from non-
observance of condenser cleanliness!
Fig.13 Changing the fl uorescent lamp
2 – Fluorescent lamp handle
3 – Casing of the fl uorescent lamp
4 – Fluorescent lamp
5 – Starting switch of the fl uorescent lamp
6 – Casing of fl uorescent lamp and
Elements of device can corrode when improper used and maintenance. To avoid that please
follow the rules:
• Do not allow contact of the surface of the device with substances containing chlorine and / or baking
soda in different varieties, which destroy the protective layer and components of the device (also
includes various stainless steel)
During maintenance services it is necessary to pay attention not to damage the data place of the device Fig. 14
(p.16), which contains signifi cant information for servicing organs and waste removal companies.
6. SERVICE
6.1. Fault identifi cation and repair
In case of any diffi culties during actuation of the device or during its exploitation, please return to these chapters in this ma-
nual, which explain the performed operation. This aims to ensure that the device is properly operated. If you still experience
diffi culties, the following hints will help you solve the problem.
The device is not working... – Make sure that:
•
The device is connected to the supply network
•
Voltage and frequency in the network are compliant with those recommended by the producer 230V/50Hz
•
The main switch is on
•
Thermostat is on (This concerns the Igloo thermostat – If only two spots are visible on the display – turn on the thermostat)
The device is operating, but the lighting is off...– Make sure that:
•
Lighting switch is turned on
•
Fluorescent lamp or starting switch of the device are not burnt
The device does not reach the proper temperature, the lighting is on...– Make sure that:
•
Lighting switch is turned on
•
Temperature setting on the thermostat is properly set
•
Thermostat works properly
•
The condenser is clean, if necessary – clean the condenser
•
Ambient temperature does not exceed 25ºC
•
Enough time has passed for products to be cooled
•
Ventilation holes of the device are not blocked
www.igloo.pl
1 - Rail
6 5
starting switch
Fig.12 Cleaning the condenser in
"Wiktoria 2" device
4
User manual Wiktoria, Wiktoria 2
en
1
2
3
15
