Fig.6 Assembly/disassembly
of elements in "Wiktoria 2" device
1 – Upper aluminium profi le of the
glass (lifted guide)
2 – Lower aluminium profi le of the
glass (catch)
3 – Bent, front glass, lifted
4- Glass side
5 – GN container
6 – Night screen
7 – GN container separator
8 – Device levelling feet
• The fi rst cleaning of the device should be provide right after unpacking, and before turning it on. The unit should
be cleaned with water at a temperature not exceeding 40°C with a neutral detergent. For washing and cleaning
the equipment it is prohibited to use products containing chlorine and sodium varieties, which destroy the protecti-
ve layer and components of the device! Any residue of adhesives or silicone on metal elements should be remo-
ved only with extraction naphtha (not applicable to items made of plastic !). Do not use other organic solvents.
When cleaning the unit is prohibited to use water jet. The unit should be cleaned with a wet rag.
After installation of the device at the destination place it should be left to rest for at least 2 hours before
turning it on (for devices with built in compressor) to set the level of refrigerant in order to prevent problems
with starting up the aggregate.
WARNING: Keep out the cooling circuit from damage!
• Place the plug of the connecting cable directly in plug-in socket (it is forbidden to connect the device by means
of extension cords or dividers!)
• Turn on the main switch Fig.7/2 (p.13) or Fig.8/2 (p.13), which activates the temperature regulator, and then
aggregate of the device
• Set the temperature on the temperature regulation panel Fig.7/1(p.13) or Fig.8/1 (p.13) (thermostat service
details on p.17 or 18)
• Turn on the lighting switch Fig.7/3 (p.13) or Fig.8/3 (p.13)
1

Fig.7 Control panel in "Wiktoria" device

1 - Thermostat (temperature regulator) panel (service details
in Chapter No. 7 p.17 or 18)
2 - Main switch (turns on/off the aggregate of the device)
3 – Lighting switch

4. EXPLOITATION

Temperature of the cooled space and aggregate operating cycle may fl uctuate. It depends on numerous factors, such
as amount and temperature of products placed in the device and temperature of the surroundings.
The device should be placed in a dry and well-ventilated place, ensuring proper air exchange (distance between the
wall and the device – min. 10 cm), out of sunlight, kept far from heat sources and devices enforcing air fl ow (ceiling
and portable ventilators, blow-in heaters). The device functions properly in a room, where temperature falls within
appropriate climatic class stated on the data plate. The operation of the device may worsen when it shall operate in
temperature lower or higher than the stated temperature range.
www.igloo.pl
1
2
2
3
3 4
1
3
2
User manual Wiktoria, Wiktoria 2
en
Fig.8 Control panel in
"Wiktoria 2" device
1 - Thermostat (temperature
regulator) panel (service
details in Chapter No. 7
p.17 or 18)
2 - Main switch (turns on/off
the aggregate of the device)
3 – Lighting switch
5
6
7
8
13
