Symbol Description For The Tubular Motor; Accessories: Shutter Suspensions - schellenberg ROLLOPOWER STANDARD Montageanleitung

SYMBOL DESCRIPTION FOR THE TUBULAR MOTOR

Running direction of the shaft
ACCESSORIES: SHUTTER SUSPENSION
To mount the paneling to the shaft, we
recommend the use of the Schellenberg
shutter suspension (item no. 19200/19400).
This allows for a secure mounting of the
shutter panel into the shaft. Very easily and
without screw connections.
19200
19400
Tubular motor
continues to run
PE
green/yellow
blue
brown
▲ ▼
black
11
Setting the end position
230V / 50 Hz
Tubular motor
stops earlier
3x
1m
GB
