4 I English
1

TECHnICAL DATA

Type
Dimensions mm
Weight kg (without fasteners)
single sequential
Recommended operating pressure
range
Maximun permissible operating
pressure
Air consumption per driving
operation
Magazine capacity.
no. of fasteners
Penetration depth setting
Fasteners: pin nails
Pin nail length mm
Wire thickness mm
Recommended lubricant
1 litre special oil. Code no.
250 cm3 grasa especial. Code no.
2

nOIsE/VIbRATIOn InFORMATIOn

Noise characteristic values *
A-weighted single-event emission
sound pressure level at work
station L pA, 1s
A-weighted sound power level
L WA, 1s, d
Vibration characteristic values**
Weighted r.m.s.-acceleration (a)
The noise level when working can exceed 85
db (A). Wear ear protection!
* Measured values determined according to
En 12549:1999.
** Measured values determined according to
IsO 8662-11:1999
3 suPPLIED WITH
1 Pin nailer
1 Tool use and safety instructions
1 Technical data sheet
1 Transport case
Karl M. Reich Verbindungstechnik GmbH
4
3485
Only those fasteners specified under technical data
(see 1) may be used.
243/256
When filling the magazine, hold the tool so that the
1.23 kg
muzzle is not pointing towards own body or towards
any other person.
Do not load the tool with fasteners with the safety
5 - 7 bar/
yoke or trigger depressed.
0.5 - 0.7 MPa
Place the tool on its side. Press the locking lever (l) and
pull the magazine rail (m) back. Introduce the pins tip
7 bar / 0.7 MPa
downwards and push the magazine rail forward until
0.76 l at 7 bar /
it locks into place.
0.7 MPa
5
115
no
The setting lever (p) is used to disable the trigger (s).
Pointer facing upwards = disabled.
25-50
0.65
6
9 4420
balancer for 10 - 20 n (1.0 - 2.0 kp),
68 3868
cable travel 1.6 m (5.2 ft).
3485
78.5 dB(A)
90.2 dB(A)
1.43 m/s2

FILLInG THE MAGAZInE

DIsAbLInG THE TRIGGER
ACCEssORIEs
3485
Code No.
40 3393
REICH ®
