GE 5/GE 5 R/GSE 5/GSE 5 R
Move the sander constantly while the sanding plate is in con-
tact with the work surface. In doing so, ensure that you move
the sander evenly and over a wide area.
If you stop the sander on the work surface or move the sander
unevenly, this may result in a disagreeable spiral pattern of
scratches and an uneven work surface.
NOTE
The wall sander features an overload cutout for protecting the
device. If the load is too great, the device switches off and
immediately restarts.

Maintenance and care

WARNING!
Before performing any work, pull out the mains plug.
Cleaning
WARNING!
Do not use water or liquid detergents.
Regularly blow out the housing interior and motor with dry

compressed air.
Blow out the sanding head and gimbal bearing with dry

compressed air.
Replacing Velcro or backing pad
Take hold of the sanding plate together with the sanding

head to prevent the sanding plate from turning.
Turn the screw in an anti-clockwise direction and remove

(Figure J).
Disassemble the sanding head.

Replace parts (Figure K).

Assemble sanding head in reverse sequence.

Replacing the brush ring (Figure L)
Remove the sanding head (see section "Replacing Velcro

or backing pad").
Loosen the retaining screws.

Take the ring out of the housing.

Insert a new brush ring into the housing and screw in the

retaining screws.
Assemble sanding head in reverse sequence.

Replacing the protective corners
(GE 5 R/GSE 5 R) (Figure M)
Remove protective corners to be replaced.

Attach new protective corners.

Repairs
Repairs may be carried out by an authorised customer service
centre only.
NOTE
During the warranty period do not loosen the screws on the
housing.
Non-compliance will deem the guarantee obligations of the
manufacturer null and void.
Spare parts and accessories
Other accessories, in particular insertion tools, can be found in
the manufacturer's catalogues.
Exploded drawings and spare-part lists can be found on our
homepage: www.flex-tools.com

Disposal information

WARNING!
Render redundant power tools unusable by removing the po-
wer cord.
EU countries only
Do not throw electric power tools into the household
waste!
In accordance with the European Directive 2012/19/EU
on Waste Electrical and Electronic Equipment and
transposition into national law used electric power tools
must be collected separately and recycled in an env-
ironmentally friendly manner.
NOTE
Please ask your dealer about disposal options!

-Declaration of Conformity

We declare under our sole responsibility that the product des-
cribed under page 6 conforms to the following standards or nor-
mative documents:
EN 60745 in accordance with the regulations of the directi-
ves 2014/30/EU 2006/42/EC, 2011/65/EU.
Responsible for technical documents:
FLEX-Elektrowerkzeuge GmbH, R & D
Bahnhofstrasse 15, D-71711 Steinheim/Murr
Eckhard Rühle
Manager Research &
Head of Quality
Development (R & D)
Department (QD)
26.09.2018
FLEX-Elektrowerkzeuge GmbH
Bahnhofstrasse 15, D-71711 Steinheim/Murr

Exemption from liability

The manufacturer and his representative are not liable for any
damage and lost profit due to interruption in business caused
by the product or by an unusable product.
The manufacturer and his representative are not liable for any
damage which was caused by improper use of the product or
by use of the product with products from other manufacturers.
Klaus Peter Weinper
15
