General information regarding pressure regulator SG3
Range of media
GB
Maximum inlet pressure
Control ranges
Proof pressure
Leak tightness
Operating temperature
Flow coefficient
Decaying inlet characteristic
Weight
Torque spindle guide
Media contact parts
Housing
Diaphragm
Seal
Valve seat
All gases that are compatible with the construction
materials. For other media, ask the manufacturer
310 bar
0 – 1.0 bar
0 – 3.4 bar
0 – 8.6 bar
0 – 17.2 bar
150% of max. inlet pressure
Valve seat: bubble-tight
Exterior: <= 2x10
-8
-40 °C to +60 °C
Cv = 1.0
<0.8 %
2.5 kg without accessories
271 Nm
316 stainless steel, nickel-plated brass
316 stainless steel or neoprene
Teflon® or Buna-N
PCTFE
48
mbar l / s He
