Control systems
CR7032
Device monitoring
Process monitoring concept
Physical memory
Memory allocation
Software/programming
Programming system
Display elements
Status indication
Operating states
No longer valid if the colours and/or
fl ashing modes are changed by the
application program�
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen
Undervoltage/overvoltage monitoring
(extended safety monitoring according to IEC 62061 and ISO 13849)
Checksum test for program and system
Excess temperature monitoring
Second switch-off mode for 8 outputs each via a relay
(according to IEC 62061 and ISO 13849)
Remanent memory: 128 Kbytes
www.ifm.com → Data sheet search → CR7032 → More information
CODESYS version 2�3 (IEC 61131-3)
LED colour Status
– Off
Yellow 1 x on
Green 5 Hz
2�0 Hz
On
Red 2�0 Hz
on
We reserve the right to make technical alterations without prior notice!
SafetyController CR7032
Technical data
Watchdog function
Flash: 4 Mbytes
RAM: 2 Mbytes
See system manual
Three-colour LED (R/G/B)
Description
No operating voltage
Initialisation or reset checks
No operating system loaded
Run
Stop
Run with error
Fatal error or stop with error
UK
CR7032 / page 2 21�08�2017
