SafetyController CR7032
Control systems
7.2 Test standards and regulations
CR7032
Safety-related characteristics
According to IEC 62061:2005
According to ISO 13849-1:2008
Test standards and regulations
Electrical tests
Climatic tests
Mechanical tests
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen
20
Safety Integrity Level Claim Limit
Probability of Dangerous Failure per Hour
Performance Level
EN 61000-6-2: 2005
EN 61000-6-4: 2007
+A1: 2011
EN 61010: 2010
UN/ECE-R10
ISO 7637-2: 2004
EN 60068-2-30: 2006
EN 60068-2-78: 2002
EN 60068-2-52: 1996
ISO 16750-3: 2012
EN 60068-2-6: 2008
ISO 16750-3: 2012
We reserve the right to make technical alterations without prior notice!
Technical data
SIL CL 2
PFH
D
PL
Electromagnetic compatibility (EMC)
Immunity
Electromagnetic compatibility (EMC)
Emission standard
Safety requirements for electrical equipment for
measurement, control and laboratory use
Emission standard
Immunity with 100 V/m
Pulse 1, severity level: IV; function state C
Pulse 2a, severity level: IV; function state A
Pulse 2b, severity level: IV; function state C
Pulse 3a, severity level: IV; function state A
Pulse 3b, severity level: IV; function state A
Pulse 4, severity level: IV; function state A
Pulse 5, severity level: III; function state C
(data valid for the 24V system)
Pulse 4, severity level: III; function state C
(data valid for the 12 V system)
Damp heat, cyclic
upper temperature 55°C, number of cycles: 6
Damp heat, steady state
Test temperature 40°C / 93% RH,
Test duration: 21 days
Salt spray test
Severity level 3 (vehicle)
Test VII; Vibration, random
mounting location: vehicle body
Vibration, sinusoidal
10���500 Hz; 0�72 mm/10 g; 10 cycles/axis
Bumps
30 g/6 ms; 24,000 shocks
1�227 x 10
-7
d
CR7032 / page 3 21�08�2017
