Wire the Helios J1 connector according to the following table of electrical connections.
Table 1 Helios Pin-out Description
Pin Function
Number
1 Immobilizer and/or
Gradual Stop
2 Door Unlock
3 RS232 TX
4 Key (Ignition)
5 Main Power 12V
6 GND
7 Key Pad/Dallas
8 Emergency Button
9 Microphone (+)
10 Speaker (+)
11 Analog 1
12 CAN High
13 Door Lock
14 Arm
15 RS232 RX
16 Door
17 Disarm
18 GND
19 Siren/Vehicle Horn Red/Black
20 Odometer
21 Microphone (-)
22 Speaker (-)
23 Analog 2
24 CAN Low
*The odometer input informs the system whether to measure mileage by counting
odometer pulses or by calculating the distance traversed by the vehicle using GPS.
The odometer can count pulses from any type of pulse generator.
The User Interface Module
Color Designation
Blue Output (-)
Gray Output (-)
Orange/Blue Communication
Yellow Input (+)
Red Power Supply
Black
Blue/White Communication
White Input (-)
Orange Audio
Violet Audio
Yellow/Blue Input (-)
Black/Gray CAN bus connection
Gray/Orange Output (-)
Orange/White Input (-)
Blue/Black Communication
Green Input (-)
Pink Input (-)
Black
Output
White/Black Pulse Counting Input (+) Connect to pulse generator.*
Green/Red Audio
Blue/Red Audio
Violet/White Input (-)
Gray/Blue CAN BUS connection
9
Notes
Install with an external relay. Refer to
Immobilizer and Gradual Stop on
page 16.
Install with an external relay. Refer to
Locking System on page 17.
Enables direct communication with a
PC. The wire bundle provides a Molex
connector.
Indicates the vehicle ignition state.
Main +12V supply. Protected by a 5A fuse.
The wire bundle provides a Molex
connector.
Hands free connection kit. The wire
bundle provides a Molex connector.
Hands free connection kit. The wire
bundle provides a Molex connector.
Used for fuel consumption.
Install with an external relay. Refer to
Locking System on page 17.
The wire bundle provides a Molex connector.
Alarm system disarming input.
Install with a relay (according to the
vehicle voltage 12V or 24V).
Hands free connection kit. The wire
bundle provides a Molex connector.
Hands free connection kit. The wire
bundle provides a Molex connector.
