Wanders recommends that the mantelpiece for built-in
!
and recessed fireplaces should be aerated at all times.
Any complaints will be dealt with after the sales firm, the installer
or the gas company has filed a complaint and sent a copy of the
purchase receipt with purchase date. Any repairs do not entitle
you to extend the guarantee term. All resulting damage and/or
consequential losses are excluded.
Installation instructions for the Square
The Square is tested in accordance with the international EN13229 standardization. This stove can be connected
to a flue tube to which several stoves are connected. The flue tube has a diameter of 200 millimetres. The
connection to the convection system has a diameter of 100 millimetres.
The heating device must be placed and connected by an acknowledged installer and according to
!
the installation instructions given below. The national and local rules and regulations for placing
and using wood-burning stoves are equally applicable. WANDERS does not give any guarantee if the
Square is connected or installed incompletely or incorrectly.
It is not allowed to build the stove in
•
stairwells, except in buildings with no more than 2 dwellings;
•
arcades and corridors accessible to the public;
•
spaces where highly flammable or explosive materials are processed or used;
•
spaces where an exhaust system is used or where a mechanical exhaust system is placed, except when the
air supply is taken directly from outside to assure a hazardless combustion.
Preparation
The chimney flue
Before placing the stove, you must observe the following points:
•
If you want to connect the stove to an existing chimney, you must first have the chimney professionally
cleaned and checked by a qualified chimney sweep company. Any cut-off or stop valves must be removed.
•
The flue tube of the stove must be connected with the chimney without diversions.
•
The underpressure in the chimney must be at least 12 Pa or 0.12 mbar.
•
The chimney flue must always end up in outlet area 1.
24
1
3
3
A X
X > 23˚
1
X
3
500 mm
X < 23˚
