6.3.2 DMX protocol

Channel 1 – Preset programs, automatic mode, sound control
DMX value
000 – 009
010 – 029
030 – 049
050 – 069
070 – 089
090 – 109
110 – 129
130 – 149
150 – 169
170 – 189
190 – 209
210 – 229
230 – 249
250 – 255
Channel 2 – Master control
DMX value
000 – 009
010 - 255
Channel 3 – Strobe control
DMX value
000 – 009
010 - 255
Channel 4 – Spot 1: Brightness red
DMX value
000 – 255
Channel 5 – Spot 1: Brightness green
DMX value
000 – 255
Channel 6 – Spot 1: Brightness blue
DMX value
000 – 255
Channel 7 – Spot 2: Brightness red
DMX value
000 – 255
Channel 8 – Spot 2: Brightness green
DMX value
000 – 255
Function
Off
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Program 9
Program 10
Program 11
Automatic mode
Sound control
Function
Off
Dimming from 0 – 100%
Function
Off
Strobe slow fast
Function
Dimming from 0 – 100%
Function
Dimming from 0 – 100%
Function
Dimming from 0 – 100%
Function
Dimming from 0 – 100%
Function
Dimming from 0 – 100%
28/31 00054242.DOC, Version 1.2
