OPERATION

The built-in control panel of the unit features four operating buttons and a display which shows all operation
statuses. After connecting the unit to the mains it requires a short initialization process and is then ready for
operation. The display shortly indicates the firmware version followed by the last operating mode. The light
set may be controlled via IR remote control or a DMX controller. The operating modes can be selected by
means of the display and the control buttons.

Operating buttons

Button
MENU
ENTER
UP
DOWN

Menu structure

Mode
Automatic mode
Sound control
Color mode
DMX mode
Slave mode
Function
Selects the operating mode or returns to the initial screen.
Activates a value to be modified or saves a value when modifying.
Selects the next menu item or increases values when modifying.
Selects the previous menu item or decreases values when modifying.
Display
A.P01-20
d.01-100
AUT
S.01-100
SOU SP.01-20
R.000–R.255
G.000–G.255
B.000–B.255
W.000–W.255
ALL
A.000–A.255
COL
U.000–U.255
S.000–S.100
ALon
d***
02CH
04CH
06CH
dПH
10CH
24CH
28CH
SLA SLAV
Show program 1-20
Brightness 1-100
Running speed 1-100
Show program 1-20
Red 0-100%
Green 0-100%
Blue 0-100%
White 0-100%
Amber 0-100%
UV 0-100%
Strobe effect
(0 = off, 1-99 = speed slow > fast,
100 = sound-controlled strobe effect)
PAR 1
PAR 2
Individual color settings for each spot
PAR 3
PAR 4
Start address (read only)
d001-511 2-channel mode and start address
d001-509
4-channel mode and start address
d001-507 6-channel mode and start address
d001-503 10-channel mode and start address
d001-489
24-channel mode and start address
d001-485 28-channel mode and start address
Slave function
