SICK DME3000-1 Profibus Operating Instructions Seite 30

Seite 30
22...23
0...7 bool
8 bool
9 bool
10 bool
11 bool
12 bool
13 bool
14 bool
15 bool
24...25 unsigned 16
26...27 unsigned 16
28...31 unsigned 32
32...35 signed 32
36...39 signed 32
40...43 unsigned 32
44...47 unsigned 32
48...57 ASCII string
58...59
60 signed Byte
61 signed Byte
62..63
Die Bit 0...7 von Octed 8 und Octed 19 sind fest auf „0". Octed 9 der Diagnosedaten spiegelt Octed 9
der übergebenen Parameter-Daten.
Die Werte für Encoder-Typ, „Measuring Step in nm" und „Distinguishable revolutions" sind fest.
Service
Supported warnings:
not used
Wave plausibility
PLL-lock detect
RS422 error
Plausibility error
Reception level too small
Temperatur error
Reference laser error
Measuring laser error
Profile version
Software version
Operating time
Offset value
Manufacturer offset value
Measuring units per revolution
Total Measuring range in measuring
units
Serial number (10 Zeichen)
oder (**********)
Reserved for future use
Sensor Temperature
attenuation (dB)
Reserved
DME 3000-111 P
Software V2.2
