OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and in DMX-controlled mode via any commercial DMX controller.
Menu structure in s
Mode
DMX mode
Automatic mode
Sound control
Color mix with Dimmer
Strobe

DMX OPERATION

Setting the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 7 control channels. To be
able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the MENU button so many times until d001 is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to set the address. Confirm with the ENTER button.
3 A dot will flash in the display when DMX signals are being received. If no control signals are available,
the dot will not flash.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
tand-alone mode
Display
d001
P000
L000
E000
SOUd
r000
g000
b000
u000
F000
d001-512 DMX starting address
Color change, "Switching", with
P000 – P255
increasing speed
Color change, "Fading", with
L000 – L255
increasing speed
Color change, "Pulsing", with
E000 – E255
increasing speed
Sound control
r000-255 Red 0-100%
g000-255 Green 0-100%
b000-255 Blue 0-100%
u000-255 White 0-100%
F000-F255
Strobe effect, with increasing speed
16/20
Function
00119979, Version 1.1
