Standard mode
Turbo mode
Remaining battery indicator switch
Lights ;
The battery remaining power is over 75%.
Lights ;
The battery remaining power is 50% – 75%.
Lights ;
The battery remaining power is 25% – 50%.
The battery remaining power is less than 25%.
Recharge the battery soonest possible.
Battery
Lights ;
The battery remaining power is over 75%.
Lights ;
The battery remaining power is 50% – 75%.
Lights ;
The battery remaining power is 25% – 50%.
Lights ;
The battery remaining power is less than 25%.
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or
malfunction. The problem may be the battery
so please contact your dealer.
NOTE
(1) To prevent the battery power consumption caused by
forgetting to turn off the LED light, the light goes off
automatically in about 2 minutes.
(2) Check the cleaner's remaining battery indicator after
switching off the main unit.
STANDARD ACCESSORIES
(1) Hose (id 38 mm × 1.5 m long) ......................................1
(2) Zoom pipe ....................................................................1
(3) Crevice nozzle .............................................................1
(4) Master nozzle...............................................................1
(5) Polyethylene bag (10 pcs.)...........................................1
(6) Battery (BSL36A18)* ...................................................2
(7) Charger (UC18YSL3)* .................................................1
(8) Battery cover* ..............................................................2
(9) Tool box* ......................................................................1
Standard accessories are subject to change without
notice.
* (NN) specifi cations is excluded.
SELECTING ACCESSORIES
The accessories of this machine are listed on page 257.
Optional accessories are subject to change without notice.
APPLICATIONS
○ General cleaning in workplaces and others.
○ Collection of fi ne dusts generated during grinding,
cutting or drilling of concrete or wood using power tools.
○ Suction of liquid such as water spilt on the fl oor.
SPECIFICATIONS
1. Power tool
Model
Item
Rated voltage
Motor
Application
Max. Airfl ow
Max. Vacuum
Details-Dry
Details-Wet
Battery available for this
tool*
Dimensions (W × D × H)
Weight**
* Existing batteries (BSL3660/3626X/3626/3625/3620,
BSL18.... and BSL14.... series) cannot be used with this
tool.
** According to EPTA-Procedure 01/2014
2. Battery
Model
Voltage 36 V / 18 V (Automatic Switching*)
Battery capacity
Available cordless
products**
Available charger
* The tool itself will automatically switch over.
** Please see our general catalogue for details.

UNPACKING

○ Carefully unpack the power tool.
○ Take out the accessories in the tank before work.
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger's power cord to the
receptacle.
When connecting the plug of the charger to a
receptacle, the charge indicator lamp will blink in red
(At 1- second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger as shown in
Fig. 2 (on page 2).
11
English
RP3608DA
36 V
DC motor
Wet and Dry type
3.5 m /min
3
20.1 kPa
8 L
6 L
Multi volt battery
331 mm × 369 mm × 382 mm
10.4 kg (BSL36A18 x 2pcs.)
10.9 kg (BSL36B18 x 2pcs.)
BSL36A18
2,450 mAh / 4,900 mAh
(Automatic Switching*)
Multi volt series, 18 V product
Sliding charger for lithium ion
batteries
