4.2

BEFESTIGUNGSELEMENTE UND WERKZEUGE

PARTS NO.
B42
SOCKET BUTTON HEAD BOLT (M8 x 1.25P x 32L)
D09
SOCKET BUTTON HEAD SCREW (M6 x 1.0P x 15L)
D10
SPRING WASHER (SW6 6.1 x 12. 2 x 1.5t)
F06
FLAT WASHER ( 10.2 x 19 x 2.0t)
F08
NUT (3/8"-16NNC)
F07
CROSS HEAD SCREW (M5 x 0.8P x 15L)
F19
FLAT WASHER ( 5.2 x 12 x 1.2t)
H04
SOCKET BUTTON HEAD SCREW (M8 x 1.25P x 19L)
H05
SPRING WASHER (SW8 8.2 x 15.4 x 2t)
F20
CROSS HEAD SCREW ( 4 x 10L)
N08
SOCKET BUTTON HEAD BOLT (M8 x 1.25P x 40L)
N09
NUT (M8 x 1.25P)
Z01
#5 L-TYPE (+ TYPE) WRENCH
Z02
OPEN END WRENCH (#8 #13 #14 #15)
F04
REAR FOOT POSITION PLATE
F18
HEX HEAD CAP BOLT (3/8"-16NNC 130L)
KAPITEL 4: t
eIlelIste und
DESCRIPTION
z
usammenbau
QUANTITY SKETCH
2
4
4
4
2
2
2
10
8
2
1
1
1
2
1
2
COLOR
OF BAG
White
Red
Yellow
Blue
Black
Pink
