Getting Started
For a complete list of replaceable accessories and part ordering
information, refer to the service manual that accompanies this
product.
8
To use the tip, hold the probe body and pull the tip shield
back. Hook the tip onto the circuit and release the shield.
Soft Case. The soft case protects the probe and allows
you to hang the probe near the point of measurement.
Install or remove the case by opening the access flaps
on the back.
When not in use, coil the leads and secure them with
the strap on the back. Use one of the loops to hang the
probe on a storage hook or utility belt.
Color Marker Bands. When you are using more than one
probe, the bands enable you to quickly distinguish
between probes and the channels they are connected to.
To use the marker bands, attach one band near the
probe head and the matching band near the compensa-
tion box.
P5210 Instructions
