General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for
future reference.
SHEAR SAFETY WARNINGS
1. Hold the tool firmly.
2. Secure the workpiece firmly.
3. Keep hands away from moving parts.
4. Edges and chips of the workpiece are sharp.
Wear gloves. It is also recommended that you
put on thickly bottomed shoes to prevent
injury.
5. Do not put the tool on the chips of the
workpiece. Otherwise it can cause damage
and trouble on the tool.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
8. Do not touch the blade or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
9. Avoid cutting electrical wires. It can cause
serious accident by electric shock.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.
Director

FUNCTIONAL DESCRIPTION

CAUTION:
Always be sure that the tool is switched off and
•
unplugged before adjusting or checking function on
the tool.
Switch action
Fig.1
CAUTION:
Before plugging in the tool, always check to see
•
GEA010-1
that the slide switch actuates properly and returns
to the "OFF" position when the rear of the slide
switch is depressed.
To start the tool, slide the slide switch toward the "I (ON)"
position. For continuous operation, press the front of the
slide switch to lock it.
To stop the tool, press the rear of the slide switch, then
slide it toward the "O (OFF)" position.
ASSEMBLY
GEB027-2
CAUTION:
Always be sure that the tool is switched off and
•
unplugged before carrying out any work on the tool.
Adjusting the blade clearance
Fig.2
Fig.3
For JS1660 Only
Adjust the clearance between the side blade and the
center blade according to the thickness of the workpiece.
First use a screwdriver to loosen the screw.
Then use the hex wrench to adjust the clearance by
tightening or loosening the bolt. There may be a slight
difference between clearances (A) and (B).
Check the smaller clearance with the thickness gauge
and adjust it.
When using the thickness gauge to adjust the blade
clearance, refer to the table.
Workpiece thickness (mm)
Less than 0.8
More than 1.3
006428
After adjusting the clearance, tighten the screw securely.

OPERATION

Lubrication
Fig.4
Before operation, lubricate the contact point of the center
blade and the pin. To keep good cutting performance,
also use a cutting lubricant from time to time during
operation.
4
Marking on thickness gauge
0.8 - 1.3
0.5
1.0
1.5
